A31 Series Single Port Manual Sampling Valve
Advantages
1. Valve diaphragm is certified with FDA and USP.
2. Valve bodies with ports are machined in one piece of forging steel, thus avoiding all crevices and fissures from welded or screwed parts.
3. Valve bodies come with welded or clamp connection, customization is acceptable.
4. Sanitary seal has good resistance to high pressure, excellent corrosion resistance and is of long service life.
5. Spring-preloading structure strengthens sealing effect and
| Valve Body Material | AISI 316L |
| Internal Surface | Mechanical Polishing Ra≤0.4μm; |
| Electropolishing | |
| Connecton Type | Welded Connection, Clamp Connection |
| Valve Body Bore Diameter | Φ8 |
| Nominal Pressure | PN16 |
| Control Type | Manual |
| Connection Type | ASME-BPE Welded, ASME-BPE Clamp |
| Diaphragm Material | PTFE |
| Operating Pressure | 0-1.0Mpa |
| Fluid Temperature | -10℃ — +150℃ |
| Structure | Single Port (With Sterilization Function), Dual-Port |
-
