Features:
1. Adopts a flameproof enclosure design with an explosion-proof rating of ⅡC.
2. Suitable for all explosion-proof areas except underground mining applications.
3. Compact structure and small footprint.
4. Easy to install, maintain and repair.
5. Large LCD screen with comprehensive information display and intuitive operation.
6. High regulation accuracy and strong anti-interference capability.
7. Stable and reliable performance with fast response.
8. Spring-eject type feedback rod for easy valve adaptation.
9. Zero air supply consumption in steady-state operation.
| Rated voltage | DC24V |
| Signal types | 0/4-20mA, 0-5/10V |
| Rated power | < 4W |
| Ambient temperature | -20 to +60℃ |
| Shell material | A380 |
| Explosion-proof type | Flameproof type |
| Explosion-proof mark | Ex db ⅡC T6 Gb/Ex tb ⅢC T80℃ Db |
| Certificate Number | GYB25.2716X |
| Protection Rating | IP66/IP67 |
| Enterprise Number | Q/JR22001-2024 |
| Certification standards | GB/T 3836.1-2021,GB/T 3836.2-2021,GB/T 3836.31-2021 |
