107 Series Threaded Manual Angle Seat Valve
| Operating pressure | 0-16bar (0-232psi) |
| Body material | CF8/CF8M/CF3M and other special materials |
| Seal material | PTFE |
| Applicable medium | Water, Alcohol, Oil, Fuel, Steam, Neutral gas or Liquid,organic solvent, weak acid or weak base solution |
| Fluid temperature | -10℃ — +180℃ |
| +25℃ — +220℃ | |
| Ambient temperature | -10℃ — +80℃ |
| Maximum fluid viscosity | 600m 2 /s |
| Connection type | Threaded, Welded, Tri-clamp, Flange |
| Leakage class | DIN EN 12266 Class A |
-
428KB PDF
